SE CAD solutions

Design automation and productivity tool for modeling and drafting

Accurate and speedy production of 3D digital prototype and workshop drawings deliverables of pressure vessels, towers, TEMA heat exchange, storage tanks with fixed roof, spherical tanks, ducts, equipment piping, and slug catchers.

Overview

SEG supports a different configuration and layout of the shell, heads, support structure, nozzles, manways, and other internal as well as external features and appurtenances is facilitated through intuitive menus. Fabrication details for shell courses, plate sizes, edge preparations, weld types, and other production details are quickly and easily specified. A complete vessel design can be configured and detailed in less than two hours including the automatic generation of drawings, bill of material, material cost report, and all other reports.

Product Description

Linked to Octave Pressure Vessel (formerly, Intergraph PV Elite) access file and compress *.xml3d file, SEG delivers significant savings over existing 3D CAD modeling and drafting methods.

Save money and time, improve efficiency

Software made by engineers for engineers. SEG makes modeling and detailing of the static equipment much easier, faster, and accurate. As a static equipment manufacturer, designer or draftsman, You can save up to 80% from your time and money. Generate 3D models and workshop drawings, in a matter of minutes.

Select different configurations

Supports a different configuration and layout of the shell, heads, support structure, nozzles, manways, and other internal as well as external features and appurtenances is facilitated through intuitive menus.

Ease of Modeling

Fabrication details for shell courses, plate sizes, edge preparations, weld types, and other production details are quickly and easily specified. A complete vessel design can be configured and detailed in hours including the automatic generation of drawings, bill of material, and material cost report, among others.

Internal and external appurtenances

SEG supports a wide range of appurtenance features and configurations Internal components including tray rings, baffles, deflectors, and other features. External components including lugs, clips, and vacuum rings. Opening closure, manways, agitator, and couplings. Nozzles with tee, flanges, elbows, reinforcement pads, insert pads, and other attachments and configurations.
